User Manual
FROG-3
Rev 19 Page72
12.2 Decal - Vinyl Stickers - Located on Outside of Buoyancy Units
Note: MDPE Buoyancy requires preparation of surface for good contact adhesion. Gently heat the contact area until the
surface is oxidised and appears shiny.
Refer to diagram FROG-3 Column Marking Plan for layout:
i. 3 off Circular FROG Logo - 250 dia.
ii. 3 off Rectangle Reflex Marine Ltd Logo – 250 x 125.
iii. 2 off Rectangle Reflex Marine Ltd URL “www.reflexmarine.com” - 250 x 100.
iv. 1 off Rectangle Reflex Marine Ltd Tel No “+44 (0)1872 321155” - 250 x 100.
v. Buoyancy columns numbered "A, B, C" Arial bold 150 mm height, black on upper buoyancy.
vi. 9 off per Reflective tape (2 x 110 mm on lower and 1 x 220 mm on upper buoyancy).
12.3 Decal - Vinyl Stickers - Located Inside of Lower Buoyancy Units
Note: MDPE buoyancy requires preparation of surface for good contact adhesion. Gently heat the contact area until the
surface is oxidised and appears shiny.
Refer to diagram FROG-3 Column Marking Plan for layout:
i. Buoyancy columns numbered "A, B, C" Arial bold 150 mm height, black (See F-ASY-01) -
Stretcher seat column marked "A" and "B" and "C" clockwise.
ii. Notice "FIX LOWER BUOYANCY UNIT B & C TO OUTSIDE OF FRAME FOR STRETCHER
TRANSFERS. (FITTINGS PLACED FROM OUTSIDE)".
iii. “NO HAND HOLD” sticker at upper/ lower buoyancy interface. One at each end of lower
buoyancy block.
iv. For unit numbers FS-001 to FS-016 the buoyancy fixings for columns B and C should be
marked with a permanent marker, "TOP B" and "BOTTOM B". This is to avoid confusion with
adjustments for stretcher mode.
12.4 Decal - Operating Instructions - Located Inside of Upper Buoyancy
Units
Note: MDPE buoyancy requires preparation of surface for good contact adhesion. Gently heat the contact area until the
surface is oxidised and appears shiny.
Refer to diagram FROG-3 Column Marking Plan for layout:
i. Operating Instructions.
ii. Seat Change out Plan.
iii. Stretcher Change Out.
iv. 2 off SWL Rating Notice "THIS UNIT IS SUITABLE FOR 3 MEN SEATED OR 1 MAN SEATED PLUS
1 STRETCHER PASSENGER TRANSFERS ONLY. 20 KG LUGGAGE PER PERSON. SWL = 330 KG".
v. 3 off Safety Notice “KEEP FEET INSIDE FROG”.
