Reflex Marine FROG-3 - Stretcher (Optional) Accessory

User Manual
FROG-3
Rev 19 Page33
5.12.5 Stretcher (Optional) Accessory
Reflex Marine Ltd provides an optional basket type stretcher as illustrated in Figure 10.
Figure 10: Basket Type Stretcher (optional)
Specifications:
Length
2180 mm
Width 1
610 mm
Depth
190 mm
Weight
10 kg
Load Limit
275 kg
Includes weight of patient, stretcher and any medical
equipment.
Operating Temperature
-40 deg C to +60 deg C
