Reflex Marine FROG-3 - Page 5

User Manual
FROG-3
Rev 19 Page5
 Section 5.12.4: Torque setting for buoyancy fixings added.
 Section 6.3: Inspection frequency table has been updated to include an
ultra-high usage category
 Section 6.4:
The support drawings detailed in the guidance notes have been
updated to the new part numbers.
New separate anti-rotation fitting check added.
New separate spring check added
Diagram 4b corrected to include a tamper proof seal
 Section 6.5:
New separate check for the anti-fouling bracket and shackle spacer
added
New separate spring check added
New alignment cross bolt check added
General formatting changes
 Section 6.6:
Dye penetration test advise added to point 1
Back up eye torque setting added
Thread lubricant application requirements added to Keel Nut check
Separate anti-fouling bracket & shackle spacer check added
Separate spring check added
Separate sliding sleeve cross bolt check added
General formatting changes
 Section 6.7:
Separate spring check added
Separate sliding sleeve cross bolt check added
 Section 6.8
Load test held for 5 mins.
 Section 6.8.2
Model numbers updated
 Section 6.10.1
New part numbers for spares kits
Thread lubricant added to relevant parts kits
1 x tamper proof seal added to the parts kits that contain type 2
keel assemblies
Single slings have been replaced with new sling kits
 Section 11.3
Parts lists have been deleted from the User Manual
 Appendix B:
Drawings have been updated with new assembly drawings.
Drawings referring to previous Frog 3 models have been removed
to avoid confusion.
 Appendix F :
New CE marking and ABS Type approval certificates attached for all
units beyond FS:412
19
 Section 6.3 Table 3:
New ‘Very Low’ Usage Category defined with corresponding
inspection frequencies.
Load Test requirements also revised.
