22 | Grandview
®
G600C Gas Fireplace
installation
Total Material
Maximum Depth: 1-1/4
”
(32 mm)
Finishing Material
Backing Material (Drywall etc.)
*Distance to
combustible material
varies with install*
OUTSIDE FINISH
Finishing Material
Backing Material (Drywall etc.)
Flush Finishing Material
CLEAN FRONT
Header Deflector
1-1/4" (32 mm)Max.
6. Slot the Header Deflector onto the back screws, then secure the with a screw through the remaining front hole on each flange.
