86 | Grandview
®
G600C Gas Fireplace
installation
Safety Screen Removal
1. Slide screen
up.
2. Slide screen
right.
3. Lower screen
down.
4. Swing screen
outwards while
keeping the
screen level
and remove.
1. To install the safety screen—Reverse steps above.
Safety Screen Installation
Glass Door Removal
1. To install the door—Reverse steps above.
1. To remove the glass door - place both hands on either side of
the latch. Pull forward then up to unlock, repeat on opposite
side.
Important: After releasing the latches, support the weight of the
door.
2. With both latches released, support the door with both hands
and tilt out to approximately a 60 degree angle.
3. Lift the door up and out of lower slots to remove.
Glass Door Installation
Latch locations
