Regency P36D-NG1 - Flush Louvers

Regency
®
P36D-1 Zero Clearance Direct Vent Gas Fireplace
5353
INSTALLATION
REGENCY
®
OPTIONS
FLUSH LOUVERS
1) Install the top louver by sliding the two
bracket clips into the brackets located
underneath the top of the fi rebox.
2) The bottom louver has a hinge that is
attached (2 screws per hinge) to the lip on
bottom of the unit.
3) Open the bottom louver. Pull the Burner
ON/OFF control box from inside the bottom
of the fi replace and position the slots in the
bracket over the 2 screws on the left side
of the bottom louver. Push down to lock into
place. Tighten the screws.
Burner ON/
OFF control
box attached
to bottom
fl ush louver.
Screws on
louver bracket
Burner ON/OFF
control box
Note: Top and
bottom louvers are
different.
