Regency
®
P36D-1 Zero Clearance Direct Vent Gas Fireplace
5757
INSTALLATION
REGENCY
®
OPTIONS
Note: The facing material has to go on after the unit is set.
1) Remove Glass Door. Refer to P36 Manual.
2) Remove 2 screws and bracket as indicated (refer to Diagram 2).
3) Install On/Off switch (refer to Diagram 3).
4) Place bracket under the Flange. Secure with 2 screws as indicated
in Diagram 4.
Diagram 2
Diagram 3
5) Loosen the 3 x #8 Phillips Head Screws located on the inside top
of the outer frame of the appliance (refer to Diagram 5).
Remove bracket
Remove both screws
On/Off Switch
Control
Mounting
Bracket
3 x #8 Phillips
Diagram 4
Diagram 5
To Next Page
