Manual CORRIGO U-SERIE 2002-09
Information series - rolling display
During normal running when the buttons are not in use a series of menu pages is
shown.
The display alternates between a general display with product description and clock,
setpoint/actual temperature, output status for the control outputs Y1,Y2 and Y3 and
setpoint, actual value and output status for supply air fan and exhaust air fan and
sepoint and actual value for the humidity control.
The initial display shows the product name, date and time.
Program version number By pressing Esc when the gerneral display is active the
product version number is displayed. For LON-models the 12 digit neuron
ID-number is also displayed
The information menu is started by leaving the main menu by means of Esc or by
leaving the keyboard unused for a ten-minute period. First, the start window will be
shown for 10 seconds and then the three displays shown above will alternate at
three-second intervals.
Main menu
Press the OK button.The information menu will stop and the main menu will open
immediately.
The main menu consists of a number of menu headings and what can be seen and
done is governed by the log-in level of the user, as described below.
When the main menu is opened CONTROL HS1 is always displayed at the top of the
display.
The arrow marker to the left of CONTROL HS1 means that this heading is marked
and pressing the OK button opens this menu and shows its submenus.
Arrows at the right of the display indicate that there are headings above and below
the text that is currently being displayed. Move by using the arrow buttons.
The main menu has the following headings:
Login
Configuration
Only shown at user level 3
Control HS1
Control HS2
(CORRIGO U20 only)
Control HW/THW
AI Analogue in
DI Digital in
AO Analogue out
DO Digital out
Scheduler
Alarm settings
Not shown in level 0
Settings Only shown in level 2 and 3
>Control HS1 
Control HS2 
*CORRIGO U20* VS1 Börv/Ärvärde VVBörv/Ärv/Utst
Må 980907 10:10 25.0ºC / 25.0ºC 60°C/60°C/45%
