Fig. 5-23: Mounting example showing central vacuum unit types 2000 and 3000
Fig. 5-24: Mounting example showing central vacuum unit type 4000
A Recommended spacing
A Recommended spacing
A= 1.8 m
min. 2 m – max. 5 m
max. 10 m
2 %
2 %
A= 1.8 m
min. 2 m – max. 5 m
max. 10 m
2 %
