Page 42 13900-103 Rev. A
Appendix B - Harness Connection List
FROM TO DESCRIPTION PART NUMBER
13900-921, J2 13900-941, J1 MAIN VIDEO HARNESS 13900-935
13960-924, J13 13900-924, J1 L/R DETECTOR HARNESS 13900-939 / -944 ASSYs
13960-924, J2 13960-938 HOME SWITCH ASSY HARNESS 13960-938 ASSY
13960-924, J8,
J10,
J12
13920-948, MOTOR X
MOTOR Y
MOTOR Z
MOTOR ASSY HARNESS 13920-948 ASSY
13960-925, J10 13930-932, J1 PRINTER POWER HARNESS 13930-932
13960-925, J11 13960-924, J1 MOTOR DATA HARNESS 13960-940
13960-925, J12 13963-921, J2 PRINTER DATA HARNESS 13930-931
13960-925, J13 13900-922, J6 TONOMETER BOARD POWER HARNESS 13960-946
13960-925, J3 13960-966, CN2 LCD DISPLAY ASSY 13960-966 ASSY
13960-925, J6 13960-924, J4 MOTOR POWER HARNESS 13960-939
13960-925, J7 13920-924, J1 KEYPAD HARNESS 13920-939
13960-925, J8 13960-966, CN1 FLAT FILM CABLE 13920-939
TRANSFORMER 13960-925, J5 TRANSFORMER HARNESS (115V) 13960-942
TRANSFORMER 13960-925, J5 TRANSFORMER HARNESS (230V) 13960-943
PWR. INPUT RECPT. CHASSIS GROUND HARNESS 13920-940
OPTICAL HEAD CHASSIS GROUND STRAP HARNESS 13960-951
13900-922, J1 13900-921, J2 MAIN VIDEO HARNESS 13922-935
13900-922, J2 13900-858 PISTON SOLENOID ASSEMBLY 13900-858
13900-922, J3 13960-925, J13 TONOMETER BOARD POWER HARNESS 13960-946
13900-922, J4 13900-932 POSITION CAMERA HARNESS (LEFT) 13960-947
13900-922, J5 13900-932 POSITION CAMERA HARNESS (RIGHT) 13960-947
13900-922, J6 13900-928 POSITION ILLUMINATOR (LEFT) 13900-928
13900-922, J7 13900-928 POSITION ILLUMINATOR (RIGHT) 13900-928
13900-922, J9 13900-925 FIXATION ILLUMINATOR 13900-937
13900-922, J10 13-00-927
13900-931
13900-926
13900-930
APPLANATION DETECTOR
PROXIMITY DETECTOR
APPLANATION EMITTER
TOUCH SENSOR
13900-938
13900-922, J13 13900-943 TRAVEL LIMIT SWITCH 13900-943
13900-921, MAIN CONTROL PCB
OPTICAL HEAD ASSEMBLY
INPUT POWER CONNECTIONS
13960-925, POWER I/O PCB
13960-924, MOTOR CONTROL PCB
