REMdevice t3 User Manual

Instruction Manual
Radio control devices T3, T5 and T7.
version 1.4 Genn. 10
Description of the coupling telegram
The telegram has a constant length, composed of 144 bits:
• 48 bits are dedicated to the start line;
• 48 bits are assigned to the coupling address between receiver and
transmitter;
• 8 bits are used for the progressive count of the telegrams;
• 16 bits implement a protection algorithm with a marked probability
of detecting errors lower than 10
-8
(less than 1 in 100,000,000);
• 24 bits are used for the control code.
The 48 address bits are used to couple the transmitter to the receiver
with a code which is set by the manufacturer and assigned univocally
to each radio control device produced using the new and exclusive
“REMSYS CODE” system.
IDENTIFICATION OF THE FUSES
Receiver (fig. 3)
• STOP RELAY fuse 5x20 4 A
• Power supply fuse
Power supply 10-30 Vdc 5x20 1.6 A
Power supply 24-48 Vac/Vdc 5x20 1 A
Power supply 48-115 Vac/Vdc 5x20 0.5 A
page 26 of 28 REMdevice
®
- ITALY

REMdevice t3 Specifications

Operating Environment

operative frequency range 1	869.700 – 870.000 MHz
operative frequency range 2	433.050 – 434.790 MHz
operating and storage temperature	-20°C / +70°C

Power

power supply option 1	12-24Vdc 1, 0A
power supply option 2	24-48Vac/dc 50-60 Hz 0.4A
power supply option 3	48-115Vac/dc 50-60 Hz 0.4A
power supply option 4	115-230Vac/dc 50-60 Hz 0.2A

Receiver Specifications

command relay contacts capacity	4A 115 Vac.
stop relay contacts capacity	4A 115 Vac.
range of control	100 mt.

Transmitter Specifications

radio frequency output power	1 to 10 mW
supply voltage	3.6 Vdc.
power consumption range	13.5 mA to 24 mA
battery	integrated lithium ions 3.6V
working autonomy	up to 1200 hours (20°C)
low battery warning	at 30 hours left

Dimensions and Weight

container dimensions	158×90×75 mm (L×H×D)
watertight case Ruby-T7 dimensions	169×266×89 mm (L×H×D)
watertight case ECOBOX dimensions	124×176×45 mm (L×H×D)
transmitter dimensions	176x85x37 mm (L×H×D)
transmitter weight	350 g
