REMdevice t3 User Manual

Instruction Manual
Radio control devices T3, T5 and T7.
version 1.4 Genn. 10
TECHNICAL CHARACTERISTICS
Parameters of the Radio Control device
- Operative frequency available in the following ranges:
869.700 – 870.000 MHz/ Channelling pitch 25 kHz/ N° channels 11
433.050 – 434.790 MHz/ Channelling pitch 25 kHz/ N° channels 60
Hamming Code Distance > 4
Maximum number simultaneous commands: 10
Command response time: 50 ms
Active stop/emergency command response time: 50 ms
Passive emergency response time: 1 sec.
Range: 100 mt.
Operating and storage temperature: -20°C / +70°C
Receiver
Radio-frequency receiver: Single Chip
Aerial: ¼ λ integrated
Power of command relay contacts: 4A 115 Vac.
Power of stop relay contacts: 4A 115 Vac.
Power supply (depending on model):
- 10-30Vdc 1,0A
- 24-48Vac/dc 50-60 Hz 0.4A
- 48-115Vac/dc 50-60 Hz 0.4A
Container Rx-DIN T7: Modulbox for assembly on guide DIN EN 50022,
degree of protection IP20, dimensions (L×H×D) 158×90×75 mm
Watertight case for outdoor assembly Ruby-T7: degree of protection IP65
Dimensions: (L×H×D) 169×266×89 mm
Watertight case for outdoor assembly ECOBOX: degree of protection IP65
Dimensions: (L×H×D) 124×176×45 mm
Transmitter
Modulation: Manchester FM encoding
Radio frequency output power: from -10 dBm to +7dBm
Oscillator: PLL digital synthesis
Aerial: ¼ λ integrated
Supply voltage: 3.6 Vdc.
Absorption: from 13.5 mA to 24 mA
Battery: integrated lithium ions 3.6V - 16.5Ah
Working life (medium power): up to 1200 hours (20°C)
Battery flat early warning: 30 hours
Casing: ABS, degree of protection IP65
Dimensions: (L×H×D) 174x85x37 mm
Weight: 350 g
REMdevice
®
- ITALY page 27 of 28

REMdevice t3 Specifications

Operating Environment

operative frequency range 1	869.700 – 870.000 MHz
operative frequency range 2	433.050 – 434.790 MHz
operating and storage temperature	-20°C / +70°C

Power

power supply option 1	12-24Vdc 1, 0A
power supply option 2	24-48Vac/dc 50-60 Hz 0.4A
power supply option 3	48-115Vac/dc 50-60 Hz 0.4A
power supply option 4	115-230Vac/dc 50-60 Hz 0.2A

Receiver Specifications

command relay contacts capacity	4A 115 Vac.
stop relay contacts capacity	4A 115 Vac.
range of control	100 mt.

Transmitter Specifications

radio frequency output power	1 to 10 mW
supply voltage	3.6 Vdc.
power consumption range	13.5 mA to 24 mA
battery	integrated lithium ions 3.6V
working autonomy	up to 1200 hours (20°C)
low battery warning	at 30 hours left

Dimensions and Weight

container dimensions	158×90×75 mm (L×H×D)
watertight case Ruby-T7 dimensions	169×266×89 mm (L×H×D)
watertight case ECOBOX dimensions	124×176×45 mm (L×H×D)
transmitter dimensions	176x85x37 mm (L×H×D)
transmitter weight	350 g
