REMdevice t3 User Manual

Instruction Manual
Radio control devices T3, T5 and T7.
version 1.4 Genn. 10
GUARANTEE CONDITIONS
REMdevice guarantees the radio control device for 12 months.
The starting date of the guarantee period is that of the transport document.
The guarantee is valid only for appliances that present manufacturing
defects. The radio control device MUST NOT have undergone attempted
repairs, tampering, or replacement of parts by personnel not authorised by
REMdevice.
The guarantee is void in the case of incorrect use or incorrect installation.
The appliances under guarantee must be repaired at an authorised service
centre or directly at REMdevice.
The components in which manufacturing defects are found will be replaced
free of charge; the transport costs for collecting and delivering the appliance
are excluded.
This guarantee does not cover parts subject to wear.
REMdevice does not accept requests for refund for machine down times,
since the operating machines are equipped with a wired pushbutton panel.
REMdevice does not answer for damage, loss, theft occurring during the
transport of new or repaired appliances, or ones to be repaired.
REMdevice does not carry out operations (under guarantee or out of
guarantee) on appliances without the serial number and without having had
prior contact with the requesting party.
Manufacturer: REMdevice
®
s.r.l. E-Mail: info@remdevice.com
http://www.remdevice.com
Registered Head Office - Commercial Offices - Production
Research and Development
REMdevice s.r.l. REMdevice s.r.l.
via Roma n. 27 via Mantegna n. 12
28010 Bogogno (NO) 36061 Bassano del Grappa (VI)
ITALY ITALY
TEL +39 0424 500 262
FAX +39 0424 508 631
Copyright © 2006 – REMdevice
®
s.r.l. All rights reserved.
The information supplied in this guide has been accurately checked, so as to
be precise and exhaustive, however REMdevice declines any responsibility in
the event of any errors and omissions.
REMdevice reserves the right to alter the specifications described at any time
and without prior notice.
It is forbidden to reproduce, transmit, transcribe or store the
information in a search system, even in part, or to translate it into
another language in any form, without prior authorisation in writing
by
REMdevice
®
s.r.l.
page 28 of 28 REMdevice
®
- ITALY

REMdevice t3 Specifications

Operating Environment

operative frequency range 1	869.700 – 870.000 MHz
operative frequency range 2	433.050 – 434.790 MHz
operating and storage temperature	-20°C / +70°C

Power

power supply option 1	12-24Vdc 1, 0A
power supply option 2	24-48Vac/dc 50-60 Hz 0.4A
power supply option 3	48-115Vac/dc 50-60 Hz 0.4A
power supply option 4	115-230Vac/dc 50-60 Hz 0.2A

Receiver Specifications

command relay contacts capacity	4A 115 Vac.
stop relay contacts capacity	4A 115 Vac.
range of control	100 mt.

Transmitter Specifications

radio frequency output power	1 to 10 mW
supply voltage	3.6 Vdc.
power consumption range	13.5 mA to 24 mA
battery	integrated lithium ions 3.6V
working autonomy	up to 1200 hours (20°C)
low battery warning	at 30 hours left

Dimensions and Weight

container dimensions	158×90×75 mm (L×H×D)
watertight case Ruby-T7 dimensions	169×266×89 mm (L×H×D)
watertight case ECOBOX dimensions	124×176×45 mm (L×H×D)
transmitter dimensions	176x85x37 mm (L×H×D)
transmitter weight	350 g
