REMKO GPS series
Unit dimensions
Series Dimensions Opening Gas supply
L W H V HB LB IS ID ØG GO GV
GPS 15 795 500 690 145 520 490 395 400 3/4“ 180 255
GPS 25 795 500 690 145 520 490 395 400 3/4“ 180 255
GPS 35 985 500 690 145 520 680 490 495 3/4“ 180 255
GPS 55 985 500 765 145 595 680 490 495 3/4“ 180 255
GPS 75 1310 500 765 145 595 1010 655 660 3/4“ 180 255
Series Horizontal discharge
A F AV TV S
GPS 15 80 80 430 120 155
GPS 25 80 80 430 120 155
GPS 35 80 80 430 120 155
GPS 55 80 80 505 120 155
GPS 75 80 80 505 120 155
Series Vertical discharge
A F AO TO S
GPS 15 80 80 145 120 155
GPS 25 80 80 145 120 155
GPS 35 80 80 145 120 155
GPS 55 80 80 145 120 155
GPS 75 80 80 145 120 155
A = Supply line
F = Flue gas line
We reserve the right to modify the dimensions and design as part of the ongoing technical development process.
(480)*
115
* Dimension for the fixed wall bracket
