Flue gas connection
Individually, the units are classified for the following
versions:
B23/C13/C33/C43/C53/C63
The installation of the flue gas and supply air duct can
take place in different ways.
e.g. Gas fireplace type B:
The combustion cycle is not sealed compared
to the environment in which it has been installed.
The combustion air is taken directly from the
installation space.
This version may only be installed in rooms that have
at least one door or window that can be opened
to the outside and have a volume of at least 4 m³
per kW total nominal heat output of the unit; or a
combustion air opening of at least 150 cm² leading
outside or two openings that have a clear cross-
section of at least 75 cm² each.
e.g. Gas fireplace type C:
The combustion cycle is sealed compared
to the environment in which it is installed.
The combustion air is fed from outside.
The units may only be operated with appropriate flue
gas pipes.
The factory components available as serial accessories
correspond to all requirements.
CAUTION
The use of plastic flue gas pipe is not permitted.
The units work with a closed combustion cycle.
The fan is located in front of the heat exchanger.
The flue gas evacuation and/or combustion air
supply must be planned and executed in observance
of the respective local guidelines.
In addition, installation on outside walls must be
coordinated with the responsible district master
sweep.
The classification of the different installation versions
takes place pursuant to the European Standard EN
1020 and/or DVGW-TRGI Directive 2008 and is a
component of the EC authorisation in the factory-
supplied design.
Installing the end pieces
The warm air heaters from the GPS range are
equipped in the rear and top section of the burner
box with openings for the extraction and flue gas
pipe. Depending on which type of installation has
been selected, it is possible to fit or relocate the end
pieces at the rear or top.
The end pieces are mounted on the rear side
of the unit in the factory. If top openings should be
required then the connections must be detached from
the rear side and the cover and seal unscrewed from
the top openings. Now screw the 90° bend inside
the burner box, in the respective direction. Insert
the end pieces in the desired position and screw
the cover and seals into the seats that are not used.
Make sure that the seal is guaranteed on the burner
box and in particular on the flue gas pipe.
Fitting the end piece seals
The scope of supply includes two seals to seal
the end pieces with the flue gas pipe and fresh air line.
These are fitted on the end pieces of the GPS units for
correct sealing.
CAUTION
If the end piece seals are not used then there is a
high risk that flue gases will be fed into the room
to be heated.
NOTE
The installer of the exhaust system is obliged to
complete the system identification (name plate)
enclosed with the exhaust system in accordance
with applicable standards and visibly attach it to the
exhaust system.
