REMKO GPS Series User Manual

42
REMKO GPS series
Technical data
We reserve the right to modify the dimensions and design as part of the ongoing technical development process.
Series
Symbol Unit
GPS 15 GPS 25 GPS 35 GPS 55 GPS 75
Nominal thermal load
Q

H
kW 16.5 27 34.8 52.2 73.5
Nominal heat capacity P
rated,h
kW 15 24.6 31.9 48.1 67.5
Minimum capacity P
min
kW 12.1 20.4 25.8 39.9 56.2
Nominal airflow volume
V

nom
m
3
/h 2,000 2,700 3100 4500 7800
Air temperature increase K 21.5 26.1 29.5 30.5 24.8
Fuel Natural gas or liquid gas
NOx class [EN1020:2009] Cl
5
CO
2
content
1)
% 8.8 ± 0.2
CO
2
content
2)
% 9.9 ± 0.4
Gas connection
4)
Inches G 3/4“ G 3/4“ G 3/4“ G 3/4“ G 3/4“
Gas flow rate (natural gas H) m
3
/h 1.75 2.86 3.68 5.52 7.78
Gas flow rate (natural gas L) m
3
/h 2.03 3.32 4.28 6.42 9.04
Gas flow rate (liquid gas) kg/h 1.35 2.21 2.85 4.27 6.01
Flue gas flow
1)

Af
kg/h 30 46 61 101 136
Flue gas flow
2)

Af
kg/h 31 48 62 103 140
Available flue gas pressure Pa 80 100 120 130 140
Exhaust gas temperature, approx. t
Af
°C 204 191 182 187 184
reqd. draft intensity Pa 0
Efficiency at nominal heating capacity
η
nom
% 81.6 81.2 82.6 82.9 82.6
Efficiency at minimum capacity
η
pl
% 83.8 84.3 84.3 84.8 84.3
Case dissipation factor F
env
% 0 0 0 0 0
Power consumption of the ignition
flame
P
ign
kW 0 0 0 0 0
Nitrogen oxide emissions (Hi) NO
x
mg/
kWh
44 30 30 47 43
Nitrogen oxide emissions (Hs) NO
x
mg/
kWh
40 27 27 42 39
Efficiency of heat emission
η
s,flow
% 93.8 92.2 91.3 90.7 92.6
Room heating annual efficiency
η
s,h
% 73.6 72.9 72.3 72.2 73.4
Power supply V/Hz 230/1~/50
Rated current A 0.62 0.86 0.89 1.43 2.14
Rated power consumption kW 0.143 0.197 0.184 0.330 0.493
Max. auxiliary energy consumption el
max
kW 0.063 0.058 0.074 0.101 0.112
Min. auxiliary energy consumption el
min
kW 0.037 0.033 0.045 0.056 0.061
Auxiliary energy consumption in sb. el
sb
kW 0.005 0.005 0.005 0.005 0.005
