Renault Clio Cup - Default Chapter; Table of Contents; Chassis

2010 Release
E-2
4 CHASSIS
CONTENTS
4 CHASSIS 2
4.1 SETUP 3
4.2 FRONT AXLE 4
4.2.1 PRESENTATION AND CHARACTERISTICS 4
4.2.2 GEOMETRY INSPECTION 7
4.2.3 GEOMETRY VARIATIONS 9
4.2.4 ADJUSTMENT OF GEOMETRY 10
4.2.5 FRONT LOAD-BEARING COMPONENTS 11
4.2.6 WHEEL PASSAGES 20
4.3 REAR AXLE 22
4.3.1 PRESENTATION AND CHARACTERISTICS 22
4.3.2 GEOMETRY VARIATIONS 24
4.3.3 ADJUSTMENT OF GEOMETRY 25
4.3.4 REAR LOAD-BEARING COMPONENTS 26
4.4 STEERING 29
4.4.1 STEERING UNIT 29
4.4.2 INTERMEDIATE SHAFT 33
4.4.3 STEERING COLUMN 34
4.4.4 ELECTRIC POWER SYSTEM 36
4.5 BRAKING SYSTEM 39
4.5.1 CHARACTERISTICS 39
4.5.2 FRONT BRAKES 41
4.5.3 REAR BRAKES 44
4.5.4 BRAKING CIRCUIT 48
4.6 WHEELS AND TYRES 54
4.6.1 CHARACTERISTICS 54
4.7 KIT EVO 2009 55
4.7.1 NEW WISHBONE MOUNTING 55
4.7.2 EXTERNAL MIRRORS 57
4.7.3 DIFFUSER 57
4.7.4 FRONT HEADLIGHTS 58
4.7.5 FRONT BUMPER 59
4.8 TIGHTENING TORQUES 63
