2010 Release
E-55
KIT EVO 2009
4.7.1 NOMENCLATURE
WISHBONES
Designation Reference Qty
Assembled wishbone with A and B casings 77 11 162 592 2
External snap ring Ø58 77 11 162 563 2
Point A spacer 77 11 162 525 4
Point B spacer 77 11 162 526 4
Ball joint Ø15 77 11 128 370 4
Internal snap ring Ø30 77 11 128 850 4
M12 deported locknut 77 03 034 248 4
M12 washer 77 11 156 931 4
CHC screw M12 x 145 77 11 162 527 2
CHC screw M12 x 86 77 11 156 908 2
BODYWORK
Black rear diffuser 77 11 162 532 1
Diffuser’s duct 77 11 162 533 2
External exhaust nozzle 77 11 162 534 2
Front bumper skin 77 11 162 535 1
Front bumper inferior plastic fence 77 11 162 536 1
Inferior deflector 77 11 162 537 1
Left aerodynamic blade 77 11 162 538 1
Right aerodynamic blade 77 11 162 539 1
Anti-fog light left cover 77 11 162 540 1
Anti-fog light right cover 77 11 162 541 1
Front left bumper support 77 11 162 542 1
Front right bumper support 77 11 162 543 1
Left halogen headlight 77 11 162 544 1
Right halogen headlight 77 11 162 545 1
Black superior bumper trim cover 77 11 162 546 1
Black inferior bumper trim cover (F1 blade) 77 11 162 547 1
Black left rearview mirror shell 77 11 162 548 1
Black right rearview mirror shell 77 11 162 549 1
Left external rearview mirror 77 11 162 550 1
Right external rearview mirror 77 11 162 551 1
Assembled Renault ensign 77 11 162 565 1
FASTENERS
Diffuser screw 77 03 017 090 2
Diffuser nut 77 03 034 276 2
Screw for diffuser’s duct 77 03 008 211 6
Nut for diffuser’s duct 77 03 046 151 6
F1 blade fitting screw 77 03 017 101 8
Screw for bumper fitting on inferior radiator support 77 03 602 206 2
Screw for bumper fitting on front quarter panel 77 03 019 211 2
Retainer for bumper fitting on superior radiator support
