Renault Clio Cup - Clio Cup Component Tightening Torque Guide; Front Axle Component Tightening Torques

2010 Release
E-63
4.8 TIGHTENING TORQUES
Parts
Tightening
torques in Nm
Specific
recommendations
FRONT AXLE
Wheels
Wheel studs 100 Copper grease
Wheel nuts 110
Wheel speed sensor 8 to 10
Drivetrain nut 280
Damper system
Upper shock absorber nut 100
Point F plate bolt on body 100
Support strut mounting bolt on pivot
holder
105
Pivot holder
Point E nut 105 Bolt class: 12.9
EE’ support
Mounting bolt on pivot holder 140
Ball joint E’ mounting bolt 26.5
Wishbone
Point A bolt 80
Point B bolt 80
Subframe
Aluminum plate mounting bolt on
subframe
100
Connecting torque rod mounting bolt on
GB yoke
105
Connecting torque rod mounting bolt on
subframe
105
Bolts for points P and P’ 120
QQ’ tie-rod mounting bolts to body 105
QQ’ tie-rod mounting bolts to subframe 80
