Renault Clio Cup - Rear Load-Bearing Components

2010 Release
E-26
4.3.4 REAR LOAD-BEARING COMPONENTS
Hub
See 4-5 Brake System/Rear brakes/Hub disc.
Damper system
- Removal
Operations Photos
1 -
Place the vehicle on a jack stand on the appropriate
side.
2 -
Remove the wheel.
3 -
Remove the lower mounting bolt (1).
4 -
Remove the upper mounting nut (2).
5 -
Remove the damper system.
- Refitting
Perform the removal steps in reverse order.
Tightening torques:
 Lower mounting bolt: 105Nm.
 Upper mounting bolt: 80Nm.
1
2
