Renault Clio Cup - Front Brake Service Procedures

2010 Release
E-41
4.5.2 FRONT BRAKES
Brake pads
- Removal
Operations Photos
1 -
Push back the pistons.
Watch out for rising brake fluid levels in
the tank.
2 -
Remove the upper spindle (1) using a drift
punch.
3 - Remove the spring and lower spindle (2).
4 -
Remove the pads, noting their position for
refitting, where appropriate.
- Refitting
Perform the removal steps in reverse order.
1
2
