Renault Clio Cup - Rear Axle, Steering, and Wheel Bearing Torques

Anti-roll bar tie-rod mounting bolts 44
Point H nut 37
Anti-rotation tie-rod mounting bolt on
wishbone
100
Anti-roll bar
Bearing mounting bolts on subframe 21
Anti-roll bar tie-rod nut 44
REAR AXLE
Wheel
Wheel bolt 110
Hub
Spindle nut 220
Damper system
Upper mounting bolt 80
Lower mounting bolt 105
Rear axle
Bearing mounting bolt on body 62
Nut for bearing mounting bolt on rear axle 125
Plate spindle on axle 71
Brake hose nut 14
STEERING
Axial ball joint
Axial ball joint 50
Point H ball joint nut 37
Wheel alignment locknut 53
Steering unit
Steering unit mounting on subframe 105
Folding yoke cam bolt 24
Steering column
Column mounting bolt on roll cage
crossmember
105
Sheath bolt 21
Sheath mounting bolt on roll cage stays 21
Intermediate shaft mounting bolt on column 34
Wheel hub bolt 44
