2010 Release
E-32
- Refitting
Operations
1 -
Position the riser shims on the subframe (ref 77 11 160 016, thickness: 5mm).
2 -
Fit the steering unit on the subframe.
3 -
Tighten the two bolts to 105Nm.
4 -
Refit the subframe (see 4-4 Front axle/Front load bearing components/Subframe).
Bellows
- Bellows assembly
When replacing an axial ball joint, new bellows MUST be refitted.
To ensure the good air balance, the steering MUST be placed at the mid-point.
1 -
Fit a nose cone on the axial ball joint in order to avoid damaging the bellows during
assembly.
2 -
Coat the bellows’ contact surface with the axial ball joint with grease to prevent the
bellows from twisting.
3 -
Attach the bellows with a new clamp (provided with the bellows).
