2010 Release
E-35
- Refitting
1 - Refit the steering column.
2 - Tighten the four bolts to 105Nm.
3 - Fit the folding yoke.
4 - Tighten the cam nut to 24Nm.
5 - Fit the sheath onto the column and tighten the 2 bolts to 21Nm.
6 - Tighten the 2 roll cage stay mounting bolts on the column to 21Nm.
7 - Place the steering wheel hub on the column.
8 - Tighten the hub mounting bolt to 44Nm.
9 - Fix the wheel on the hub.
10 - Connect the power steering module wiring harness.
11 - Refit the dashboard and central console.
