Renault Clio Cup - Page 38

2010 Release
E-38
- Removal
Operations Photo
1 -
Remove the steering column (see previous
paragraph).
2 -
Remove the 4 unit mounting bolts (1) on the
steering column.
3 -
Remove the power steering module from the
column.
Note:
keep the four spacers.
It is important not to run the EPS unit
when the column has been removed in
order to not offset the position sensor
(see 4-4 Steering/EPS unit).
- Refitting
Operations
1
-
Refit the power steering module on the column, using the 4 spacers (ref 77
11 160 149).
2
-
Tighten the 4 bolts (1) to 6Nm.
3
-
Refit the column (see 4-4 Steering/Steering column).
