Renault Clio Cup - Page 47

2010 Release
E-47
- Refitting
Operations
1 -
Fit the hub. disc (1) on the spindle.
2 -
Position the spindle bolt.
3 -
Refit the brake caliper and tighten the bolts to 105Nm.
4 -
Refit the pads (see corresponding paragraph).
5 -
Refit the wheel and tighten the bolts to 130Nm.
6 -
Tighten the spindle nut to 220Nm.
7 -
Press the brake pedal several times in order to place the piston in contact with the
pads.
- Checking play
Check axial play using a dial gauge mounted on the disc: max. 0.03 mm.
