3.07
AIR CONDITIONING
Controls
A Air temperature control
B Switches on air recirculation
C Adjusts the volume of air blown
into the passenger compartment
D Switches on air conditioning
E Air distribution control
Adjusting the air temperature
Move control A.
To the right: maximum possible
temperature
To the left: minimum possible
temperature
Adjusting the amount of air
blown into the passenger
compartment
Move control C.
Passenger compartment ventilation
is by blown air. The blower
determines how much air enters the
passenger compartment but vehicle
speed also has some influence on
this.
The further the control is positioned
to the right, the greater the quantity
of air blown into the passenger
compartment.
Note: To close off the air intake
completely and switch off the
system, set control C to 0.
