3.04
HEATING / VENTILATION
Controls
A Air temperature control
B Switches on air recirculation
C Adjusts the volume of air blown
into the passenger compartment
D Air distribution control
Adjusting the air temperature
Turn button A.
Turning the knob to the right
increases the temperature.
Adjusting the amount of air
blown into the passenger
compartment
Move control C.
Passenger compartment ventilation
is by blown air. The blower
determines how much air enters the
passenger compartment but vehicle
speed also has some influence on
this.
This principle improves the
stability of the air temperature in
the passenger compartment.
