FUSES
CORRECT INCORRECT
Fuse box 1
If an electrical component fails to
operate, check that the fuses are
soundbeforemakingfurther
investigations.
Open cover A.
Refer to the fuse allocation label
(shown on the page opposite) on the
cover to identify the fuses.
It is not advisable to use the free
fuse locations.
Check the fuse in
question and, if
necessary, replace it with
a fuse of the same rating.
If you fit an over-rated fuse, it
may cause the electrical circuit
to overheat (risk of fire) in the
event of a consumer drawing an
excessive current.
Use tweezers to remove fuse 2.
Toremovethefusefromthe
tweezers, slide the fuse to the side.
In accordance with local
legislation or as a precautionary
measure:
Obtain a box of spare bulbs and
fuses from your RENAULT
Dealer.
