1.17
FRONT SEATS
To move a seat forwards or
backwards
Lift bar 2. Adjust the seat and
release it. Make sure the seat is
correctly locked in position.
To adjust the height of the seat
Lift handle 1. Release it when the
seat is at the desired position.
Note: lift yourself out of the seat
while you are raising the seat
height.
To tilt the seatback
Use lever 6.
Heated seats
Press switch 5.
An indicator light lights up on the
switch.
Front armrests 4
To adjust the lumbar support on the
driver’sseat
Turn tumblewheel 3
We would advise you not to
recline the seatbacks too far
to ensure that the
effectiveness of the seat
beltsisnotreduced.
Make sure the seatback is locked in
place correctly.
Nothing should be placed on the
floor (area in front of driver) as
objects could slide under the pedal
during sudden braking manoeuvres
and obstruct its use.
