NU650_12_G2-FRA.qxd 9/12/04 11:17 Page 2.16
TRAFIC - NU 650-12 X83
C:\Documentum\Checkout\NU650-12_T2-ENG.win 17/12/2004 7:17
-page16
2.16
QUICKSHIFT GEARBOX
Gear lever 1
- This allows you to shift directly
from first gear to reverse gear, to
select reverse gear and neutral and
to change gear in manual mode.
- It also allows you to switch
between manual and automatic
modes at any time, with the engine
switched on and reverse gear
engaged, by moving the lever to
the left.
Note: the selector lever
automatically returns to the centre
position after use.
Display
2 Automatic mode
3 Brake pedal depressed indicator
light
4 Gear display
5 Snow mode
6 Gearbox fault warning light
7 Load mode
The gear engaged (1st, 2nd..., 6th, N,
R) is shown in the instrument panel
display. In automatic mode, (A) is
displayed.
