TOWING
Fitting the towing ball hitch
Fit the spacer, with two mounting
holes 1 at the top.
Screw the towing ball hitch into the
two mounting holes 1.
Tightening torques (in daNm:
decaNewtonmetres)
Large diameter bolt: 21.
Small diameter bolt: 13.5.
Permissible nose weight,
maximum permissible towing
weight, braked and unbraked:
refer to the information on Weights
in Section 6.
Refer to the manufacturer's
instructions for information on
how to fit and use the roof rack bar.
Please keep these instructions with
therestofthevehicle
documentation.
Fitting towing equipment
A:929mm
