3.02
AIR VENTS (air outlets)
1 - Left-hand side window demister
outlet.
2 - Left-hand air vent.
3 - Windscreen demisting outlets.
4 - Centre air vents.
5 - Control panel.
6 - Right-hand side air vent.
7 - Right-hand side window demister
outlet.
8 - Front footwell heater outlets.
