NU650_12_G3-FRA.qxd 9/12/04 11:22 Page 3.03
TRAFIC - NU 650-12 X83
C:\Documentum\Checkout\NU650-12_T3-ENG.win 17/12/2004 7:21
-page3
3.03
AIR VENTS/WINDSCREEN AND REAR SCREEN DE-ICING
Centre air vents
Air flow
Move tumblewheel 1 (beyond the
pointofresistance).
:maximum opening.
:closed
Direction
Right/left: Move tab 2.
Up/down: press or lift tab 2.
Side air vents
Air flow
Move tumblewheel 3 (beyond the
point of resistance).
: maximum air flow
:closed
Direction
Right/left: move tab 4.
Up/down: press or lift tab 4.
Heated rear windows
With the engine running,press
button 5 (the indicator light lights
up on the instrument panel.)
This function also de-ices and
demists the electric rear-view
mirror (if the vehicle is fitted with
one).
