ENGINE OIL LEVEL (continued)
Topping up/filling
The vehicle must be on level ground
and the engine should be switched
off and cold (for instance, before the
engine is started up for the first time
in the day):
- Unscrew cap 1.
- unclip funnel 3 from its housing if
necessary;
- open the upper and lower covers
of the funnel;
- position it over the oil filling neck;
- top up the level (for your
information, the difference in
volume between the minimum
and maximum reading on dipstick
2 is between 1.5 and 2 litres
depending on the engine);
- wait for approximately two
minutes to allow the oil to flow
into the engine;
- check the level using the dipstick
2 (as explained above);
Do not exceed the max level and
remember to refit cap 1 and stow
way funnel 3.
