1.51
INSTRUMENT PANEL (continued)
The presence and operation of the warning and indicator lights described below depend on the vehicle
equipment and country.
4 Multifunction display
(continued)
4a Fuel level gauge
The number of squares lit
shows the fuel level. When it is
at minimum, the squares
disappear and the low fuel
level warning light comes on .
4b Coolant temperature indicator
Under normal use, four squares
are lit. The number of squares
lit depends on the engine
coolant temperature. There is
no warning unless the last three
squares light up.
5 Multifunction key
Pressing the key repeatedly lets
youselectinformationonthe
display, reset the trip mileage
recorder or set the time on the
clock in the instrument panel.
6 Speedometer (km or miles per
hour)
Overspeed buzzer
Depending on the vehicle, a
buzzer sounds for
approximately 10 seconds
every 40 seconds, as long as the
vehicle is travelling in excess of
74.56 mph (120 km/h).
7 Airbag warning light
This lights up when the
ignition is switched on
and goes out after a few
seconds.
If it does not light up when the
ignition is turned on or if it
flashes, there is a fault in the
system. Consult your RENAULT
Dealer as soon as possible.
Not used
7 Seat belt not fastened
warning light
Door(s) open warning
light
Not used
Exhaust gas monitor
warning light
For vehicles equipped
with this option, the light
comes on when the ignition is
switchedonthengoesout.
If it lights up continuously,
contact your RENAULT Dealer
as soon as possible.
If it flashes, reduce the engine
speed until the light stops
flashing.
Consult your RENAULT Dealer
as soon as possible.
Refer to the advice on
anti-pollution, fuel economy
and driving in Section 2.
Not used.
