Renesas RA Family EK-RA4M3 v1 – User's Manual

R20UT4803EG0101 Rev 1.01 Page 6 of 29

Jan.06.21 Nov.09.20

Figure 2. EK-RA4M3 Board Bottom Side

1.1 Assumptions and Advisory Notes

1. It is assumed that the user has basic understanding of microcontrollers and embedded systems

hardware.

2. It is recommended that the user refers to the EK-RA4M3 Quick Start Guide to get acquainted with the kit

and the Quick Start example project that EK-RA4M3 board comes pre-programmed with.

3. Flexible Software Package (FSP) and Integrated Development Environment (IDE) such as e

studio are

required to develop embedded applications on EK-RA4M3 kit.

4. Instructions to download and install software, import example projects, build them and program the

EK-RA4M3 board are provided in the quick start guide.
