1. Kit Overview
The EK-RA4M3, Evaluation Kit for RA4M3 MCU Group, enables users to seamlessly evaluate the features of
the RA4M3 MCU group and develop embedded systems applications using Flexible Software Package
(FSP) and e
2
studio IDE. The users can utilize rich on-board features along with their choice of popular
ecosystems add-ons to bring their big ideas to life.
The key features of the EK-RA4M3 board are categorized in three groups (consistent with the architecture of
the kit) as follows:
MCU Native Pin Access
• R7FA4M3AF3CFB144 MCU (referred to as RA MCU)
• 100 MHz, Arm
®
Cortex
®
-M33 core
• 1 MB Code Flash, 256 KB SRAM
• 144 pins, LQFP package
• Native pin access through 4 x 40-pin male headers
• MCU and USB current measurement points for precision current consumption measurement
• Multiple clock sources - RA MCU oscillator and sub-clock oscillator crystals, providing precision
24.000 MHz and 32,768 Hz reference clock. Additional low-precision clocks are available internal to the
RA MCU
System Control and Ecosystem Access
• USB Full Speed Host and Device (micro AB connector)
• Three 5 V input sources
 USB (Debug, Full Speed)
 External power supply (using surface mount clamp test points and power input vias)
• Three Debug modes
 Debug on-board (SWD)
 Debug in (ETM, SWD, and JTAG)
 Debug out (SWD)
• User LEDs and buttons
 Three User LEDs (red, blue, green)
 Power LED (white) indicating availability of regulated power
 Debug LED (yellow) indicating the debug connection
 Two User buttons
 One Reset button
• Five most popular ecosystems expansions
 2 Seeed Grove
®
system (I2C/Analog) connectors
 SparkFun
®
Qwiic
®
connector
 2 Digilent Pmod
TM
(SPI and UART) connectors
 Arduino
TM
(Uno R3) connector
 MikroElektronika
TM
mikroBUS connector
• MCU boot configuration jumper
Special Feature Access
• 32 MB (256 Mb) External Quad-SPI Flash
