Renesas RZ Series

RZ/G, RZ/V
Series
RZ Family / RZ/G, RZ/A Series 2. Functional Specifications
R01UH0990EJ0101 Rev.1.01 Page 34 of 83
Jul 28, 2022
Table 2.2 List of Pin Function Selection Used on Each Module Board (10/18)
Pin
Location
Pin Name
RZ/G2UL
Pin Function
RZ/A3UL
Pin Function
RZ/Five
Pin Function
Description
SMARC
Pin No.
SMARC
Pin Name
A21
P18_5/IRQ7/
RSPI0_SSL/
SCI0_CTS#/
RTS#/
USB1_OVRCUR/
SCI1_RXD/
SCIF4_TXD
IRQ7
IRQ7
IRQ7
Ethernet PHY_1 (KSZ9131RNXC),
used as an intrupt signal
—
—
N3
P3_0/ET0_RXC/
RX_CLK/
SSI1_BCK/
POE0#/MTIOC0A
ET0_RXC/
RX_CLK/
SSI1_BCK
ET0_RXC/
RX_CLK/
SSI1_BCK
ET0_RXC/
RX_CLK/
SSI1_BCK
Ethernet PHY_0 (KSZ9131RNXC)
Carrier Board Connector, connected
to Audio Codec (IC2)
S42
I2S0_CK
P2
P3_2/ET0_RXD0/
SSI1_TXD/
POE8#/MTIOC0C
ET0_RXD0/
SSI1_TXD
ET0_RXD0/
SSI1_TXD
ET0_RXD0/
SSI1_TXD
Ethernet PHY_0 (KSZ9131RNXC)
Carrier Board Connector, connected
to Audio Codec (IC2)
S40
I2S0_
SDOUT
R3
P3_3/ET0_RXD1/
SSI1_RXD/
POE10#/
MTIOC0D
ET0_RXD1/
SSI1_RXD
ET0_RXD1/
SSI1_RXD
ET0_RXD1/
SSI1_RXD
Ethernet PHY_0 (KSZ9131RNXC)
Carrier Board Connector, connected
to Audio Codec (IC2)
S41
I2S0_SDIN
R2
P4_0/ET0_RXD2/
RRRSPI2_CK/
MTIOC8A/
MTIOC2A/
USB1_VBUSEN
ET0_RXD2/
RSPI1_CK
ET0_RXD2/
RSPI1_CK
ET0_RXD2/
RSPI1_CK
Ethernet PHY_0 (KSZ9131RNXC)
Carrier Board Connector, connected
to PMOD0 connector (J1)
P56
SPI1_CK
R1
P4_1/ET0_RXD3/
RSPI1_MOSI/
MTIOC8B/
MTIOC2B/
USB1_OVRCUR
ET0_RXD3/
RSPI1_MOSI
ET0_RXD3/
RSPI1_MOSI
ET0_RXD3/
RSPI1_MOSI
Ethernet PHY_0 (KSZ9131RNXC)
Carrier Board Connector, connected
to PMOD0 connector (J1)
P58
SPI1_DO
M3
P2_2/ET0_TX_
COL/SSI0_TXD/
CAN1_TX_
DATARATE_EN/
MTCLKC/
SCI0_TXD/
RSPI0_MOSI
ET0_TX_COL
ET0_TX_COL
ET0_TX_COL
Unused
—
—
M6
P2_3/ET0_TX_
CRS/SSI0_RXD/
CAN1_RX_
DATARATE_EN/
MTCLKD/
SCI0_RXD/
RSPI0_MISO
ET0_TX_CRS
ET0_TX_CRS
ET0_TX_CRS
Unused
—
—
M1
P1_1/
ET0_TX_CTL/
TX_EN/
RSPI0_MOSI/
CAN0_TX/
MTIOC1B
ET0_TX_CTL/
TX_EN/CAN0_
TX
ET0_TX_CTL/
TX_EN/CAN0_
TX
ET0_TX_CTL/
TX_EN/CAN0_
TX
Ethernet PHY_0 (KSZ9131RNXC)
Carrier Board Connector, connected
to CAN0 connector (CN15)
P143
CAN0_TX
K6
P2_1/
ET0_TX_ERR/
SSI0_RCK/
CAN1_RX/
MTCLKB/
SCI0_CLK/
RSPI0_CK
CAN1_RX
CAN1_RX
CAN1_RX
Carrier Board Connector, connected
to CAN1 connector (CN16)
P146
CAN1_RX
M2
P1_0/ET0_TXC/
TX_CLK/
RSPI0_CK/
CAN_CLK/
MTIOC1A
ET0_TXC_TX_
CLK/P1_0
ET0_TXC_TX_
CLK/P1_0
ET0_TXC_TX_
CLK/P1_0
Ethernet PHY_0 (KSZ9131RNXC)
P113
GPIO5
