RZ Family / RZ/G, RZ/A Series 5. Appendix
R01UH0990EJ0101 Rev.1.01 Page 78 of 83
Jul 28, 2022
5.2 How to Identify Each SMARC Module Board
The differences between each SMARC Module Board are as follows. This picture is of the RTK9743U11C01000BE.
Table 5.1 Comparison of the RTK9743U11C01000BE and the RTK9743F01C01000BE
Type Name
RTK9743U11C01000BE
RTK9743F01C01000BE
IC1
RZ/G2UL (R9A07G043U11GBG)
RZ/Five (R9A07G043F01GBG)
Table 5.1 Comparison of the RTK9743U11C01000BE and the RTK9763U02C01000BE
Type Name
RTK9743U11C01000BE
RTK9763U02C01000BE
IC1
RZ/G2UL (R9A07G043U11GBG)
RZ/A3UL (R9A07G063U02GBG)
Table 5.2 Comparison of the RTK9763U02C01000BE and the RTK9763U02C01001BE
Type Name
RTK9763U02C01000BE
RTK9763U02C01001BE
IC2
Not mounted
OctaFlash
IC3
Not mounted
OctaRAM
IC9
QSPI flash memory
Not mounted
Figure 5.4 Comparison of Each SMARC Module Board
