RZ Family / RZ/G, RZ/A Series 5. Appendix
R01UH0990EJ0101 Rev.1.01 Page 80 of 83
Jul 28, 2022
3. Insert the replacement the SMARC Module Board diagonally, then roll the board parallel to the RZ SMARC
Series Carrier Board and fix it with screws.
Figure 5.7 How to install the SMARC Module Board
