30
Outer
diaphragm
Swarf deector
LP2DD – LP2HDD LP2 – LP2H
Weak link screw
Wash clean
Cap (4Nm
[3.0lbf.ft]
approx)
C spanner
Stylus
Inner
diaphragm
Cap (nger tight)
Metal eyelid
Spring
Front O-ring
Stylus
Service and maintenance
