2.10
RTS basics
RTS specification
Principal application Tool measuring and broken tool detection on vertical and horizontal
machining centres and gantry machining centres.
Overall dimensions Length with disc stylus 116.40 mm (4.58 in)
Length with square stylus 119.58 mm (4.71 in)
Width 62.50 mm (2.46 in)
Height with disc and square
stylus
107.50 mm (4.23 in)
Weight (with disc stylus) With batteries
Without batteries
870 g (30.69 oz)
820 g (28.92 oz)
Transmission type Frequency hopping spread spectrum (FHSS) radio
Radio frequency 2400 MHz to 2483.5 MHz
Switch-on methods Radio M-code
Switch-off methods Radio M-code
Operating range
Up to 15 m (49.2 ft)
Receiver/interface RMI-Q or RMI-QE combined antenna, interface and receiver unit
Sense directions ±X, ±Y, +Z
Mounting M12 (½ in) T bolt (not supplied)
Optional SPIROL® pins to allow accurate remounting
Unidirectional
repeatability
1.0 µm (40 µin) 2σ
1
Stylus trigger force
2 3
1.3 N to 2.4 N, 133 gf to 245 gf (4.7 ozf to 8.6 ozf) depending on the
sense direction
Stylus overtravel XY plane
+Z plane
±3.5 mm (0.14 in)
6 mm (0.24 in)
Environment IP rating IPX8 (EN/IEC 60529)
Storage temperature
–25 °C to +70 °C (–13 °F to +158 °F)
Operating temperature +5 °C to +55 °C (+41 °F to +131 °F)
Battery types 2 × AA 1.5 V alkaline or 2 × AA 3.6 V lithium-thionyl chloride (LTC)
Battery reserve life Approximately one week after a low battery warning is rst given
Typical battery life See table on page 2.9
Low battery indication Blue flashing LED in conjunction with normal red or green probe
status LED
Dead battery indication Constant or flashing red
1
2
3
Performance specification is tested at a standard test velocity of 480 mm/min (18.9 in/min) with a 35 mm stylus.
Significantly higher velocity is possible depending on application requirements.
Trigger force, which is critical in some applications, is the force exerted on the stylus by the tool when the probe
triggers. The maximum force applied will occur after the trigger point (overtravel). The force value depends on
related variables including measuring speed, machine deceleration and system latency.
These are the factory settings; manual adjustment is not possible.
