4.0 SETTING UP.
4.1 CONTROL PCB WIRING.
Connect main cable to Control PCB as per figure 4.1.
Control board connectors
1
2
3
4
5
6
7
8
9
10
11
Black
Red
Brown
Grey
Orange
Yellow
White
Pink
Blue
Turquoise
Violet
Figure 4.1
