System Bus right
Add-On modules can be
connected here
6
Pressure port
for dynamic
pressure
Pressure port
for static pressure
USB connector
mini usb connector (5 poles)
RS 232
connector
Speed sensor
impeller-sensor connection
external beeper
connection (especially for
motor pilots)
Battery case
silicon cover
M4 threaded sleeve
for any kind of mounting. Make sure
that the threaded sleeve is screwed in
to the correct depth (max. 8 mm).
