Renschler CoMo AV - The como AV Displays

3
Bat. full
Bat. empty
Analog-Vario-Display
(direct-vario)
The position of the needle is quickly
and precisely discernible. Shows
immediate climb- or descend-rate up
to 10 m/sec (current value shown on
display: 1,7 m/sec climb-rate)
GPS-State-Indication
This indication flashes
when the instrument is
seeking satellites. When
ever a satellite is found,
one more dot will light
up. All dots on means
that the GPS receives 6-
12 satellites.
Battery-State-Indication
The number of dots indicates the
remaining battery life (more
details on battery-life are found
on the Page-Indication "page 2")
Audio-Indication
Shows if the acoustic
function is set to "soft",
"loud" or "off".
OLC-Logger-Indication
shows if the instrument
is recording flight data
(only with built-in OLC
logger)
Page-Display
in adjustment mode:
hints for operation
Profile-State-Indication
Shows which profile is activated
(one dot = profile 1).
1.2 The CoMo AV Displays
Piezo Beeper
for audio variometer.
