EN 133
It is necessary to configure the TouchDisplay as a repeater when the main control is located
at a distance too far away from the ventilator unit. It is possible that a signal generated by the
main control does not reach the ventilator unit. By installing an extra TouchDisplay (configured
as repeater) closer to the ventilator, the generated signal of the main control will be passed on
to the repeater. The repeater then transmits the signal to the ventilator unit.
Remark: only use this setting when absolutely necessary!
8.2.2 • Programming the TouchDisplay as Repeater
• Select the INSTALLER MENU - DEVICE SETTINGS on the
second- dary control and press n .
• “Select KNX Repeater” by pressing n .
➊
➋
