Ellice
®
30
13. MONTAGE DES
LAMES
Placez les deux lames extérieures dans le
cadre. Faites attention à l’orientation de la
lame.
A
Le côté avec 2 axes, grand axe et petit axe
est le côté du moteur.
B
Le côté avec 1 axe est le côté sans moteur.
C
Lame de renforcement : se reconnaît grâce
aux axes plus épais que les lames stan-
dards.
D
S’utilise à partir des dimensions suivantes :
pour une Ellice
®
avec pivot ≥ 4325 mm on
fournit une lame de renforcement.
Pour une Ellice
®
avec un Pivot ≥ 5615 mm
on fournit 2 lames de renforcement.
Montage des lames de renforcement, voir
rubrique 14.
Montage des lames Lineo LED, voir
rubrique 19.
Inclinez la lame et glissez l’axe du côté
sans moteur le plus profondement possible
dans le trou prévu dans le profil cadre
pivot.
E
Redressez la lame et glissez l’axe de l’autre
côté dans le trou prévu dans le profil cadre
Pivot du côté opposé.
F
Fixez la lame sur l’axe du côté sans moteur
à l’aide d’un clips.
G
Répétez l’opération pour toutes les lames.
13. MOUNTING THE
BLADES
Put the two external blades into the frame.
Carefully check the orientation of the
blade.
A
The side with two shafts, the big one and
the little shaft, is the motor side.
B
The side with 1 shaft is the non-motor side.
C
Reinforced blade: this can be recognized
by the thicker shaft compared to standard
blades.
D
They are used on dimensions starting from
the following: We supply 1 reinforced
blade with an Ellice
®
with Pivot ≥ 4325
mm. We supply 2 reinforced blades with
an Ellice
®
with Pivot ≥ 5615 mm.
For fitting these reinforced blades, see
section 14.
For fitting Lineo LED blades, see section 19.
Keep the blade at an angle and slide
the shaft on the non-motor side as far as
possible into the hole provided in the Pivot.
E
Now position the blade straight again
and slide the shaft on the other side into
the hole provided in the opposite Pivot.
F
Lock the blade onto the shaft on the non-
motor side with the clips provided.
G
Repeat these steps for all the blades.
13. MONTAGE DER
LAMELLEN
Platzieren Sie die zwei äußersten Lamellen
in den Rahmen. Achten Sie auf die Orien-
tierung der Lamelle.
A
Die Seite mit zwei Achsen, große Achse
und kleine Achse, ist die Motorseite.
B
Die Seite mit einer Achse ist die Nicht-Mo-
torseite.
C
Verstärkungslamelle: erkennbar an den
dickeren Achsen als bei den Standardla-
mellen.
D
Kommen ab den folgenden Abmessungen
vor: Bei Ellice
®
mit Pivot ≥ 4.325 mm wird
eine Verstärkungslamelle mitgeliefert. Bei
Ellice
®
mit Pivot ≥ 5.615 mm werden zwei
Verstärkungslamellen mitgeliefert.
Für die Montage dieser Verstärkungslamel-
len siehe Abschnitt 14.
Für die Montage der Lineo-LED-Lamellen
siehe Abschnitt 19.
Halten Sie die Lamelle schräg und schie-
ben Sie die Achse an der Nicht-Motorseite
so weit wie möglich in das vorgesehene
Loch des Pivots.
E
Halten Sie die Lamelle nun wieder gerade
und schieben Sie die Achse an der ande-
ren Seite ebenfalls in das vorgesehene
Loch des gegenüberliegenden Pivots.
F
Sichern Sie die Lamelle an der Achse an
der Nicht-Motorseite mit den vorgesehenen
Klipps.
G
Wiederholen Sie dies für alle Lamellen.
13. MONTEREN VAN DE
LAMELLEN
Plaats de twee uiterste lamellen in het
kader. Kijk goed naar de oriëntatie van de
lamel.
A
Kant met 2 assen, grote as en kleine as, is
motorzijde.
B
Kant met 1 as is de niet-motorzijde.
C
Verstevigingslamel: te herkennen aan de
dikkere assen als de standaard lamellen.
D
Komen voor vanaf volgende afmetingen;
Bij een Ellice
®
met pivot ≥ 4325 mm wordt
1 verstevigingslamel meegeleverd.
Bij een Ellice
®
met pivot ≥ 5615 mm
worden 2 verstevigingslamellen meegele-
verd.
Plaatsing van deze verstevigingslamellen,
zie rubriek 14.
Plaatsing van Lineo LED lamellen, zie
rubriek 19.
Hou de lamel schuin en schuif de as aan
de niet-motorzijde zo ver mogelijk in het
voorziene gat van de pivot.
E
Hou de lamel nu terug recht en schuif de as
aan de andere zijde ook in het voorziene
gat van de tegenoverliggende pivot.
F
Borg de lamel op de as aan de niet-motor-
zijde met de voorziene clips.
G
Herhaal dit voor alle lamellen.
