XCell® ATF 2 and 4 Stainless Steel Housings
User Guide
8
SG-SSATF24 rev 1
Figure 1. Pressure and exhaust strokes
Note: XCell® ATF Stainless Steel Housings require a vacuum (negative pressure) to move the
diaphragm to its lowest position. Positive pressure from the bioreactor is insufficient to
completely deflate the diaphragm, necessitating the use of vacuum to ensure proper
XCell® ATF Stainless Steel Housing operation.
3. About this document
Several user attention phrases are used throughout this manual. Each phrase should draw the
following level of attention:
Table 1. Explanation of user attention phrases
Phrase Description
Note: Points out useful information
IMPORTANT
Indicates information necessary for proper
instrument operation
CAUTION
Cautions users regarding potentially hazardous
situations regarding user injury or damage to the
instrument if the information is not heeded
WARNING!
Warns users that serious physical injury can result if
warning precautions are not heeded
4. Safety precautions
Table 2. Explanation of symbols
Symbol Description
Caution
Risk of danger. Consult Operating Instructions for nature of hazard and
corrective actions. Potentially hazardous situation which, if not avoided, may
result in property/equipment damage
Safety
Alert
Symbol
Hazard to personnel is present, the safety alert symbol is omitted when the
hazard is related to property/equipment damage only
From bioreactor
To bioreactor
Filtered harvest
HFF
HFF
Diaphragm
Diaphragm
Positive air pressure
Negative air pressure
Filtered harvest
