General information
3-7
Figure 3-4: Side view
8 Battery (charged) LED. Flashes when battery is charging. On continuously when
battery is charged. Off when ventilator is running on battery, when a battery er-
ror or failure is detected, or when the ventilator is off and AC power is not con-
nected.
9 ON/Shutdown key with LED. Turns on AC power and initiates ventilator shutdown.
LED is continuously on when AC power is connected.
Number Description
1 Ventilation vents. Allow intake of air for delivery to the patient.
2 Air inlet filter (under side panel). Filters the air for delivery to the patient.
Number Description
